Description

*Support FLYSKY radio’s i-BUS2 protocol

servo parameter setup / data logging / warning / and other functions

*Support the high speed mode of brands’ radio

Noble NB4 Pro modes: NOR / SR / SFR

Futaba modes: NOR / SR / UR

SANWA modes: NOR / SHR /SSR / SUR / SXR

*Support the Power HD program box PG-CB63

*four-pole brushless motor

high performance/ long Life-span/ heat-resistant/ faster response

Torque(6.0V): 36.0 kg-cm / (499.9 oz/in)

Torque(7.4V): 42.0 kg-cm / (583.3 oz/in)

Torque(8.4V): 50.0 kg-cm / (694.4 oz/in)

Speed: 0.11 sec (6.0V) ©¦ 0.09 sec (7.4V)

Speed: 0.08 sec (8.4V)

Operating Voltage: 6.0 ~ 8.4 DC Volts

Weight: 63 g (2.22 oz)

Bearing Type: Ball Bearing x 2

Motor Type: Brushless Motor

Gear Type: 7075+Steel

Operating Temperature: -20~60°C

Working frequence: 1520 / 1666hz

Size: 41.0 x 20.0 x 29.0 mm ( 1.61 x 0.79 x 1.14 in)

Max current: 7.5A
