Description

Dead band: 0.002ms (Default)

Control System: +Pulse Width Control

Working frequence: 1520µs / 333hz

(RX) Required Pulse: 3.0 ~ 5.0 Volt Peak to Peak Square Wave

Operating Voltage: 4.8 ~ 5. 0 V DC Volts

Operating Temperature Range: -10 to + 60 Degree C

Operating Speed (4.8V): 0.120 sec/60° degrees at no load

Operating Speed (5.0V): 0.115 sec/60° degrees at no load

Stall Torque (4.8V): 3.10 kg.cm (43.0 oz/in)

Stall Torque (5.0V): 3.22 kg.cm (44.7 oz/in)

360° Änderbar: YES

Motor Type: Coreless Motor

Potentiometer Drive: Indirect Drive

Driver Type: FET

Bearing Type: Dual Ball Bearings

Gear Type: Metal + Aluminum-magnesium alloy Gears

Programmierbar: YES

Connector Wire Length: 15.0 cm (5.9 in)

Abmessungen: 22.5X10X23.5 mm (0.89x 0.39x 0.93 in)

Gewicht: 9.5 g (0.335 oz)
